   N - Standard Pump
HOME > Á¦Ç°¼Ò°³ > N - Standard Pump



Group - N type ÆßÇÁ´Â Seepex ¸ðµç ÆßÇÁÀÇ ±âº» °ñ°ÝÀÌ µÇ´Â ÆßÇÁÀÔ´Ï´Ù.
Seepex ¸¸ÀÌ °¡Áø 6LÀÇ ºÎµå·¯¿î ¿¬¼Ó¼º Cavity¸¦ ¸¸µé¾î »ê¾÷ü ¿ä±¸ÇÏ´Â ´Ù¾çÇÑ Á¡µµ¼º
À¯Ã¼¸¦ °í¾Ð·ÂÇÏ¿¡¼­ ¾ÈÁ¤µÇ°Ô À̼ÛÇÕ´Ï´Ù.

»ç¿ëÀ¯·® : 30§¤/h ~ 500§©/h
»ç¿ë¾Ð·Â : ~ 40kg/§² ±îÁö

À¯·®, ¾Ð·ÂÀº À¯Ã¼ÀÇ Á¡¼º, ¼ºÁúµî¿¡ µû¶ó SeepexÀÇ ±â¼úÁøÀÌ Á÷Á¢ ¼³°èÇÕ´Ï´Ù.


Best Basis
seepex pumps of product group N form the basic product group of all seepex progressive cavity pumps. They can be supplied with various rotor/stator geometries (conventional, 6L and Tricam geometry) and can be used in almost all branches of industry for pumping low-viscous to highly viscous media with or without solids. Numerous application advantages ensure an especially economical application.

N - Standard pump
Flow rate | 30 l/h -500 m³/h | 0.132 USGPM - 2,200 USGPM
Pressure | up to 48 bar | 720 PSI
PDF »ó¼¼¼³¸íº¸±â
  Advantages and Characteristics

  • Steady, low-pulsation pumping
  • High self-priming rate, even with air or gas-liquid mixtures of up to 8.5 mWS
  • Installation possibilities in all positions
  • Large spherical entrance port
  • Direction of rotation and thus delivery flow reversible

Ranges
  Range BN

  • Short, compact design with directly flange-mounted drive (block design)
  • Conveying capacities: 30 l/h - 500 m³/h
    0.132 USGPM - 2,200 USGPM
  • Pressures: up to 48 bar | 720 PSI

  Range NS

  • Drive casings with free shaft end facilitate universal configuration of drives through flexible couplings or V-belts.
  • Conveying capacities: 30 l/h - 500 m³/h
    0.132 USGPM - 2,200 USGPM
  • Pressures: up to 48 bar | 720 PSI
